GÉNÉRALITÉS
|
Marque |
TP-Link |
Modèle |
Archer VR300 |
Catégorie |
Modems & Routeurs |
CARACTERISTIQUES MATERIELLES
|
Interface |
3 10/100 RJ45 LAN Ports
1 10/100 RJ45 LAN/WAN Port
1 RJ11 Port |
Bouton |
WPS Button
Power On/Off Button
Reset Button |
Alimentation |
12V/1A |
Standards VDSL2 |
ITU G.993.2, Up to 17a pro¬le (POTS)
ITU-T G.993.5 (G.vector)
// G.998.4 (G.INP) |
Standards ADSL |
Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),
// G.994.1 (G.hs),
// G.995.1 |
Standards ADSL2 |
ITU-T G.992.3 (G.DMT.bis),
ITU-T G.992.4 (G.lite.bis) |
Standards ADSL2 |
// G.992.5 |
Dimensions (LxPxH) |
385*290*76mm |
Type d’antenne |
4 fixed external antennas |
CARACTÉRISTIQUES WIFI
|
Standards WiFi |
IEEE 802.11a/n/ac 5 GHz,
IEEE 802.11b/g/n 2.4 GHz |
Débit WiFi |
867 Mbps at 5 GHz
300 Mbps at 2.4 GHz |
Puissance de transmission |
2.4GHz <20dBm(EIRP)
5GHz <23dBm(EIRP) |
Fonctions WiFi |
Access Point / Wireless Bridge, Wireless EnableDisable, SSID Broadcast EnableDisable |
Sécurité WiFi |
WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryptions, QSS(WPS) |
CARACTERISTIQUES LOGICIELLES
|
Qualité de Service QoS |
ATM QoS, Bandwidth Control |
Sécurité |
NAT Firewall, Access Control, IP and MAC Address Binding |
Modes opératoires |
VDSL/ADSL Modem Router, Wireless Router |
Administration |
Web Based Con¬guration(HTTP), Remote management,
command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware
Upgrade, Diagnostic Tools |
DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
Redirection de port |
Virtual Server, Port Triggering, DMZ, ALG, UPnP |
DNS dynamique |
DynDns, NO-IP |
VPN Pass-Through (ne bloque pas un lien VPN) |
PPTP, L2TP, IPSec Passthrough |
Protocoles |
Supports IPv4 and IPv6 |
Protocoles ATM/PPP |
ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MERIPoE (RFC 1483
Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs |
Fonctions avancées |
Parental Control, Network Address Translation(NAT),
Port Mapping(Grouping), Static Routing, RIP v1/v2(optional), DNS Relay,
DDNS, IGMP V1/V2/V3 |
Réseau invité |
2.4 GHz guest network, 5 GHz guest network |
AUTRES
|
Certification |
CE, RoHS, RCM |
Contenu de l’emballage |
- AC1200 Wireless VDSL/ADSL Modem Router Archer VR300
- External Splitter
- RJ11 DSL Cable
- RJ45 Ethernet Cable
- Power Adapter
- Quick Installation Guide
|
Système requis |
- Microsoft Windows XP/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
- Internet Explorer, Firefox, Chrome, Safari or other Java-enabled browser
- Subscription with an Internet Service Provider (for Internet access)
|
Environnement |
- Operating Temperature: 0℃~40℃
- Storage Temperature: -40℃~70℃
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
|
